Popis produktu:

Key Features

   X3D Turbo Mode : Unleash new era gaming performance
   DDR5 OC up to 8400MT/s
   AMD Socket AM5 : Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
   Digital twin 8+2+1 phases VRM solution
   Dual Channel DDR5 : 4*DIMMs with AMD EXPO™Memory Module Support
   WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
   EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
   EZ-Latch Click : M.2 heatsinks with screwless design
   Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.
   Ultra-Fast Storage : 1*M.2 slots, including PCIe 5.0 x4
   Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard Ext.
   Fast Networking : 2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
   Extended Connectivity : HDMI
   PCIe UD Slot : PCIe 5.0 x16 slots with 10X strength for graphics card & Better Heat dissipation effect


   CPU
   AMD Socket AM5, support for:
   AMD Ryzen™ 9000 Series Processors/
   AMD Ryzen™ 8000 Series Processors/
   AMD Ryzen™ 7000 Series Processors
   (Go to GIGABYTE's website for the latest CPU support list.)
   Chipset
   AMD B850
   Memory
   Support for DDR5 8400(OC) / 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
   2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
   Dual channel memory architecture
   Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
   Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
   (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
   Onboard Graphics
   Integrated Graphics Processor with AMD Radeon™ Graphics support:
   - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

   * Support for HDMI 2.1 version and HDCP 2.3, and HDR.
   ** Support for native HDMI 2.1 TMDS compatible ports.

   (Graphics specifications may vary depending on CPU support.)
   Audio
   Realtek® ALC4080 CODEC
   High Definition Audio
   2-channel
   LAN
   Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
   Wireless Communication module
   Realtek® Wi-Fi 7 RTL8922AE
   - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
   - BLUETOOTH 5.4
   - Support for 11be 160MHz wireless standard
   (Actual data rate may vary depending on environment and equipment.)

   * Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.)
   ** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.
   Expansion Slots
   1 x PCI Express x16 slot, integrated in the CPU:
   ? AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode
   ? AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
   ? AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode

   * The PCIEX16 slot can only support a graphics card or an NVMe SSD.
   Storage Interface
   1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:
   ? AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
   ? AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
   ? AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
   1 x M.2 connector on the back of the motherboard (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSDs
   2 x SATA 6Gb/s connectors
   RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices

   * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.

   RAID 0 and RAID 1 support for SATA storage devices
   USB
   CPU:
   - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
   - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
   Chipset:
   - 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
   - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
   - 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
   Internal I/O Connectors
   1 x 24-pin ATX main power connector
   1 x 8-pin ATX 12V power connector
   1 x CPU fan header
   1 x CPU fan/water cooling pump header
   1 x system fan header
   2 x addressable RGB Gen2 LED strip headers
   1 x RGB LED strip header
   2 x M.2 Socket 3 connectors
   2 x SATA 6Gb/s connectors
   1 x front panel header
   1 x speaker header
   1 x front panel audio header (routed from the adapter card on the rear panel)
   1 x USB Type-C® header, with USB 3.2 Gen 2 support
   1 x USB 3.2 Gen 1 header
   1 x USB 2.0/1.1 header
   1 x reset jumper
   1 x Clear CMOS jumper
   1 x chassis intrusion header
   Back Panel Connectors
   1 x Q-Flash Plus button
   1 x HDMI port*
   2 x antenna connectors (2T2R)
   1 x USB Type-C® port, with USB 3.2 Gen 2 support
   2 x USB 3.2 Gen 2 Type-A ports (red)
   2 x USB 3.2 Gen 1 ports
   2 x USB 2.0/1.1 ports
   1 x RJ-45 port
   2 x audio jacks

   * Actual support may vary by CPU.
   I/O Controller
   iTE® I/O Controller Chip
   H/W Monitoring
   Voltage detection
   Temperature detection
   Fan speed detection
   Water cooling flow rate detection
   Fan fail warning
   Fan speed control

   * Whether the fan speed control function is supported will depend on the fan you install.
   BIOS
   1 x 256 Mbit flash
   Use of licensed AMI UEFI BIOS
   PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
   Unique Features
   Support for GIGABYTE Control Center (GCC)

   * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

   Support for Q-Flash
   Support for Q-Flash Plus
   Support for Smart Backup
   Bundled Software
   Norton® Internet Security (OEM version)
   LAN bandwidth management software
   Operating System
   Support for Windows 11 64-bit
   Form Factor
   Mini-ITX Form Factor; 17.0cm x 17.0cm
