Popis produktu:

Feature
Storage System Type: DAS
Form Factor: Rack-mount
Device Location: Plug-in Module
Storage
Provides Data Channel: SAS
Provides Internal Drive Bay Dimension: 3.5"
Supports Number of Devices: 60
Storage Hard Drive
Hard Disk Drive Quantity: 60 x 6 TB, SAS, 7200 rpm, 128 MB Cache, Plug-in-Module
Interface
Interface Provided: QSFP+: 4x
Management Port: 2x (RJ-45)
Miscellaneous
Mounting Capability: Rackmount
Standard Rack Height: 4 U
External Colour: Silver
Package Type: Box
Power
Power Device Type: Power Supply - hot-plug
Power Device Location: Plug-in-module
Power Device Installed Quantity: 2
Power Device Maximum Quantity Supports: 2
Redundant Power Device Installed Quantity: 1+1
Maximum Output Power: 1650 W
Maximum Input Voltage: 240 V
Minimum Input Voltage: 200 V
Maximum Input Frequency: 63 Hz
Minimum Input Frequency: 47 Hz
Environment
Maximum Operating Ambient Temperature: 35 °C
Minimum Operating Ambient Temperature: 5 °C
Maximum Operating Humidity: 80 %
Minimum Operating Humidity: 8 %
Dimensions & Weight Device
Depth (mm): 983 mm
Height (mm): 174.8 mm
Width (mm): 424 mm
Nominal Weight: 93.71 kg
Features
60 integrated Ultrastar® drive modules
Available with 512e or 4Kn sector size (by part number)
Host connectivity 2 x SAS QSFP+ receptacles per IO Module; optional connectivity cables are available
QSFP+ to HD mini SAS cables for host
QSFP+ to QSFP+ cables for daisy-chaining*
Hot Swappable: two power supplies (with integrated fans), drive modules, and IO modules
Fully compliant with SAS 3.0 specification for operation up to 12Gbps
Cable management arm simplifies maintenance of hot-swappable CRUs
SCSI Enclosure Services (SES-3)
5-year limited warranty on Ultrastar HDD modules, 3-year limited warranty on all other components
