Tech Specs

Display
11.6” FHD (1920 x 1080)
Optional 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen
User selectable touch mode for Finger/Water, Glove, or Stylus programmable function

Operating System
Windows® 11 Pro 64-bit

Processor
Intel® Pentium® Gold Processor 8505 (12MB Cache, up to 4.4 GHz, 1P+4E cores)

Memory
1 slot 8GB (4800MHz DDR5)

Storage
128GB NVMe PCIe SSD

Graphics
Intel® UHD Graphics

Camera
Integrated 2.0 MP front-facing camera
Optional 11.0 MP auto-focus rear camera with flash

Keyboard & Input
6 buttons (2 user-definable keys)

Audio
Integrated microphone
Intel® High Definition Audio Compliant
Integrated speaker x 1

I/O Ports
Thunderbolt 4 x 1
USB 3.2 Gen2 (type A) x 1
Micro HDMI x 1
Audio in/out (combo jack) x 1
microSD card (microSDXC) x 1
Docking connector (35-pin Pogo) x 1
Nano SIM card x 1
DC-In jack x 1
Optional 10/100/1000 Ethernet (RJ-45) x 1
Optional smart card reader x 1
Optional 1D/2D barcode reader x 1
Optional RF antenna pass-through for GPS and WWAN

Expansion Slots
Optional RJ-45 x 1 or HF-RFID (NFC) or smart card reader or MSR+smart card reader or RJ-45/RS-232/smart card reader

Wireless & Communications
Intel® Wi-Fi 6E AX211 (802.11 ax)
Bluetooth® V5.3
Optional dedicated GPS module (UBLOX-NEO-M8N)
Optional GPS and 4G LTE multi-carrier mobile broadband
Optional RF antenna pass-through for GPS and WWAN

Security
TPM 2.0
NIST BIOS compliant
Stealth mode
Kensington lock
Optional night vision mode
Optional smart card reader
Optional HF-RFID (NFC) reader

Power
AC adapter : 100-240V, 50Hz-60Hz, 65W
Main battery Li-Ion, 11.1V, 3950mAh, 8.5 hours
Optional long life battery Li-Ion 11.1V, 6900mAh, 15 hours

Dimension & Weight
299 mm (L) x 192 mm (W) x 20 mm (H)
1.2 kg

Warranty
3-year limited warranty standard
