Popis produktu:

Key Feature

   Form Factor: M.2 2280
   Interface: PCI-Express 4.0 x4, NVMe 1.4
   Total Capacity: 2000GB*
   Sequential Read Speed : up to 7300 MB/s**
   Sequential Write speed : up to 6850 MB/s**
   Wear Leveling, Over-Provision technologies
   TRIM & S.M.A.R.T supported
   AES-256 Supported
   Warranty: Limited 5-years

Interface
PCI-Express 4.0 x4, NVMe 1.4
Form Factor
M.2 2280
Total Capacity
2000GB
NAND
3D TLC NAND Flash
External DDR Cache
DDR4 2GB
Sequential Read speed
Up to 7300 MB/s
Sequential Write speed
Up to 6850 MB/s
Dimension
80 x 22 x 3.5 mm (Double Side)
Mean time between failure (MTBF)
1.6 million hours
Max. Operating Power
Read: 8.1W
Write: 7.4W
Power Consumption (Idle, PS3)
30mW
Power Consumption(PS4, L1.2)
3mW
Temperature (Operating)
0°C to 70°C
Temperature (Storage)
-40°C to 85°C
Warranty

   1. Limited 5-years or 1400TBW.
   2. Limited warranty based on 5 years or 1400TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
   *TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.
   3. When the usage of an NVME SSD as indicated by the "Percentage Used" (SMART ID: 05) in SMART page of "GIGABYTE SSD toolbox" reaches 100 means out of warranty. (A new unused product will show the number of 0)

Note

   • Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
   • Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
   • Speeds based on internal testing. Actual performance may vary.
   • 1GB = 1 billion bytes. Actual useable capacity may vary.
