Popis produktu:

Installation Type Wall,Ceiling,T-Rail
Dimensions without packaging (H x W x D) [mm(in.)] 220 mm x 50 mm
Weight without packaging [kg(lb)] 1.08 kg
Power supply mode DC/ PoE
Input voltage range [V] DC: 12 V ± 10% PoE: 802.3at/af
Service port surge protection PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion B Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B
Maximum number of physical ports on the entire device GE (RJ45) x 1, 10M/100M/1000M auto-sensing GE (RJ45) x 1, 10M/100M/1000M auto-sensing
Long-term operating temperature [°C(°F)] -10°C to 50°C (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [°C(°F)] –40°C to +70°C
Long-term operating relative humidity [RH] 5% RH to 95% RH
Long-term operating altitude [m(ft.)] –60 m to +5000 m (–196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa] 53kPa - 106kPa ETSI 300 019-2-3
Ground floating ground
Radio number 3
MIMO spatial streams Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2 Radio 2 (5 GHz): 4x4
Wi-Fi standard 2.4G:802.11b/g/n/ax 5G:802.11a/n/ac/ac wave2/ax
Radio interface Built-in smart antennas
Antenna gain 2.4G: 4 dBi/chain (peak) 2 dBi (combined gain) 5G: 5 dBi/chain (peak value) 3 dBi (combined gain) BLE:4 dBi
Maximum transmit power 2.4G: 22 dBm/chain 25 dBm (combined power) 5G: 20 dBm/chain 23 dBm (combined power) 5G: 20 dBm/chain 26 dBm (combined power) BLE < 10 dBm
