Popis produktu:

Certification EMC certification Safety certification Manufacturing certification
Chassis material Metal
Static power consumption [W] 5.18
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 250 mm x 180 mm (1.72 in. x 9.84 in. x 7.09 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 250 mm x 187 mm (1.72 in. x 9.84 in. x 7.36 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 113.0 mm x 310.0 mm x 240.0 mm (4.45 in. x 12.20 in. x 9.45 in.)
Chassis height [U] 1
Installation type Rack mounting,Desk mounting,Wall mounting
Weight without packaging [kg(lb)] 1.34 (2.95)
Weight with packaging [kg(lb)] 2.07 kg (4.56 lb)
Typical power consumption [W] 10.31
Typical heat dissipation [BTU/hour] 35.18
Maximum power consumption [W] 10.94
Maximum heat dissipation [BTU/hour] 37.33
MTBF [years] 102.91
MTTR [hours] 2
Availability > 0.99999
Maximum number of physical ports on the entire device 10
Maximum number of 2.5GE ports 2
Maximum number of GE ports 10
Maximum number of FE ports 10
Long-term operating temperature [°C(°F)] –5°C to +40°C (41°F to 104°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F).
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.)
Power supply mode AC built-in
Rated input voltage [V] AC input: 100–240 V AC; 50/60 Hz
Input voltage range [V] AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz
Maximum input current [A] 0.8 A
Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV
Ingress protection level (dustproof/waterproof) IP20
Heat dissipation mode Natural heat dissipation
100% power consumption [W] 10.35
