Popis produktu:

Technical Specification
System
System Type: Server
System Form Factor: Rack-Mountable
Processor
Supported CPUs: EPYC 7002 Series
CPU Socket Standard: Socket SP3
CPU Maximum Quantity Supports: 1
Quantity of Mainboards Supported: 1
Memory
Memory Type: DDR4 SDRAM
Memory Form Factor: DIMM 288-pin
Provides Error Checking Method: ECC
Maximum Installable System Memory Storage Capacity: 4 TB
Memory Slot Total Quantity: 16
Memory Features: Registered
Load Reduced
Eight DDR Channels
Controller
Integrated: Storage Controller:
SATA (4)
Storage Controller:
PCIe/SATA (2 x M.2)
Storage Controller:
PCIe NVMe (12 x U.2)
Remote Management Controller:
Gigabit Ethernet (RJ-45)
Video Output
Video Controller Form Factor: Integrated
Video Chipset: Aspeed AST2500
Networking Specifications
Networking Form Factor: Integrated
LAN Chipset: Broadcom BCM5720
LAN: Gigabit Ethernet
Data Link Protocol Supports: Gigabit Ethernet/Fast Ethernet/Ethernet
Bay Provided
Number of 2.5-inch Hot-Swap Drive Bays: 16
Slot Provided
PCI Express 4.0 x16: 2
Interface Provided
USB 3.2 Gen 1: 2 (USB 3.2 (type A))
Serial: 1 (9-pin DB)
VGA: 1 (15-pin D-sub)
LAN: 1 (RJ-45)
Management Port: 1 (RJ-45)
Power
Power Device Type: Power Supply - redundant
Power Device Location: Internal
Input Voltage: AC 100-240 V
Power Device Installed Quantity: 2; Redundant (1+1)
Power Device Maximum Quantity Supports: 2
Maximum Output Power: 850 W
Miscellaneous
External Colour: Black
Mounting Capability: Rackmount
Standard Rack Height: 1 U
Environment
Maximum Operating Ambient Temperature: 35 °C
Maximum Operating Humidity: 90 %
Minimum Operating Ambient Temperature: 10 °C
Minimum Operating Humidity: 35 %
Dimensions & Weight Device
Height (mm): 43 mm
Depth (mm): 680 mm
Width (mm): 438.5 mm
Nominal Weight: 10.5 kg
