Ubiquiti Professional-grade 32-port, Layer 3 Etherlighting™ switch for high-capacity 25G SFP28 co USW-Pro-XG-Aggregation
Ubiquiti Professional-grade 32-port, Layer 3 Etherlighting™ switch for high-capacity 25G SFP28 co USW-Pro-XG-Aggregation
| Výrobca |
Ubiquiti |
|
|---|---|---|
| Kód | ITA373317 | |
| Part No. | USW-Pro-XG-Aggregation | |
| Dostupnosť po pobočkách | ||
| DPH | 23% | |
| Vaša cena s DPH |
2 941.39 €
bez DPH 2 391.37 €
|
|
| Vaša cena bez DPH | ||
| Garancia ceny | Našli ste inde na internete nižšiu cenu? Informujte nás! | |
|
|
||
| Objednať | ||
Záruka koncový zákazník: 2 Roky
Záruka firma: 2 Roky
Výrobca:
Kód: ITA373317
Part No.: USW-Pro-XG-Aggregation
Záruka firma: 2 Roky
Výrobca:
Ubiquiti
Kód: ITA373317
Part No.: USW-Pro-XG-Aggregation
Professional-grade 32-port, Layer 3 Etherlighting™ switch for high-capacity 25G SFP28 connections. Technical Specifications Overview Dimensions 442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9") Port Layout 25G SFP28 32 (25G/10G/1G) Redundancy DC Power Backup ...
Ubiquiti Professional-grade 32-port, Layer 3 Etherlighting™ switch for high-capacity 25G SFP28 co USW-Pro-XG-Aggregation
Obchod si vyhradzuje právo na zmenu ceny až po potvrdenie objednávky. Obrázok má len ilustračný charakter.
Diskusia (0)
Poslať info
- +Akcia
- +JARNÉ POMÔCKY
- +PC, NOTEBOOKY
- +MOBILY, TABLETY, HODINKY
- +PC KOMPONENTY
- +PERIFÉRIE
- +HERNÁ ZÓNA
- +ČIERNA TECHNIKA
- +MALÁ BIELA TECHNIKA
- +VEĽKÁ BIELA TECHNIKA
- +SOFTWARE, E-KNIHY
- +MICROSOFT SOFTVÉR
- +ŠPORT, ZDRAVIE
- +ZÁHRADA, HOBBY
- +NÁBYTOK
- +FOTOVOLTAIKA
Naposledy navštívené
| Kód | Názov produktu | Vaša cena |
|---|
Podrobnosti o produkte
Popis produktu:
Professional-grade 32-port, Layer 3 Etherlighting™ switch for high-capacity 25G SFP28 connections.
Technical Specifications
Overview
Dimensions
442.4 x 43.7 x 480 mm
(17.4 x 1.7 x 18.9")
Port Layout
25G SFP28
32
(25G/10G/1G)
Redundancy
DC Power Backup
Layer 3
Yes
Form Factor
Rack Mount (1U)
Etherlighting™
Yes
Performance
Switching Capacity
1.6 Tbps
Total Non-Blocking Throughput
800 Gbps
Forwarding Rate
1.2 Bpps
Supported VLANs
1,000
MAC Address Table Size
32,000
L3 Table Size
ARP Entries
128,000
IPv4 Routes
256,000
Packet Buffer Size
8 MB
Access Lists
IPv4
256
MAC
256
Layer 3 Features
DHCP Server (Local Networks)
Yes
DHCP Relay
Yes
Inter-VLAN Routing (Local Networks)
Yes
Static Routing (Local Networks)
Yes
Layer 2 Features
LACP Port Aggregation
Yes
STP & RSTP
Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
Yes
IGMP Snooping
Yes
802.1X Control
Yes
MAC-Based ACLs & Device Isolation
Yes
DHCP Snooping & Guarding
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
MAC Address Blocking
Yes
IP-Based ACLs & Network Isolation
Yes
MAC-Based Port Restriction
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
LLDP-MED
Yes
Voice VLAN
Yes
Loop Protection
Yes
Hardware
Max. Power Consumption
200W
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP RPS DC input
Power Input Method
AC input
Power Supply
AC/DC, internal, 200W
Supported Voltage Range
100—240V AC
Management
Ethernet
AR
Heat Dissipation (Excluding PoE Output)
457 BTU/hr
Weight
Without mounting bracket: 7.1 kg (15.7 lbs)
With mounting bracket:7.2 kg (15.9 lbs)
Enclosure Material
SGCC steel
Mount Material
SGCC steel
Supported Rack Depth
482.6 mm (19") four-post racks
Posts depths ranging from 600 to 1,066 mm (23.6-42”)
LCM Display
1.3" touchscreen
ESD Protection
Air: ± 12kV, contact: ± 8kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
Etherlighting™
SFP28
Yes
LEDs
RPS
Yes
NDAA Compliant
Yes
Certifications
CE, FCC, IC
