Popis produktu:

CPU
AMD Fusion APU E-450 Dual-Core onboard Processors
Supports AMD® Turbo Core Technology

Chipset
AMD FCH A50M (Hudson M1)

Memory
2 x DIMM, Max. 8GB, DDR3 1333/1066 MHz Non-ECC, Un-buffered Memory
Single Channel Memory Architecture
* Refer to www.asus.com or user manual for the Memory QVL (Qualified Vendors Lists).
* Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows® OS when you want to install 4GB or more memory on the motherboard.

Graphic
Integrated ATI Radeon™ HD 6320 GPU
Multi-VGA output support : HDMI/DVI ports
- Supports HDMI with max. resolution 1920 x 1080 @ 60 Hz
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz

Expansion Slots
1 x PCIe 2.0 x16 (x4 mode)

Storage
Built-in Controller :
5 x SATA 6Gb/s port(s), gray
1 x eSATA 6Gb/s port(s), red

LAN
Realtek® 8111E , 1 x Gigabit LAN Controller(s)

Bluetooth
Bluetooth V3.0+HS
ASUS BT GO! Utility

Audio
Realtek® ALC892 8-Channel High Definition Audio CODEC *1
Audio Feature :
- DTS Surround Sensation UltraPC

USB Ports
NEC® USB 3.0 controller :
4 x USB 3.0 port(s) (2 at back panel, blue, 2 at mid-board)
Built-in Controller :
8 x USB 2.0 port(s) (4 at back panel, black+red, 4 at mid-board)

Special Features
ASUS BT GO! :
- Folder Sync
- BT Transfer
- Shot & Send
- BT to Net
- Music Player
- Personal Manager
ASUS Exclusive Features :
- MemOK!
- AI Suite II
- Ai Charger
- Anti-Surge
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-pipe solution
- ASUS Fan Xpert
ASUS EZ DIY :
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2

Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)
1 x Bluetooth module(s)
1 x DVI-I
1 x HDMI
1 x eSATA 6Gb/s
1 x LAN (RJ45) port(s)
2 x USB 3.0
4 x USB 2.0
1 x Optical S/PDIF out
3 x Audio jack(s)
2 x Wi-Fi antenna port(s)

Internal I/O Ports
1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
5 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 4-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s)
1 x Chassis Intrusion connector(s)
1 x MemOK! button(s)
1 x Turbo Key II switch(es)

Accessories
User's manual
I/O Shield
2 x SATA 6Gb/s cable(s)
2 x Wi-Fi Antenna(s)

BIOS
32 Mb Flash ROM , EFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, ACPI 2.0a, SM BIOS 2.6 , Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen Function

Support Disc
Drivers
Anti-virus software (OEM version)
ASUS Update
ASUS Utilities

Form Factor
Mini ITX Form Factor
6.7 inch x 6.7 inch ( 17 cm x 17 cm )

Note
*1: Use a chassis with HD audio module in the front panel to support an 8-channel audio output.
