Aten 12-Key Network Remote Pad (VP2730) VPK312K1-AT-G

12-key Network Remote Pad for ATEN Presentation Switches
Easy pairing with a Presentation Switch via the host Presentation Switch's web console
Fully customizable for the functions and layout of the keys
Dual-color button LEDs for clear indication and visibility

The VPK312 is a 12-key, network-based remote pad designed for use with ATEN Presentation Switches. It offers an intuitive interface for function control of the connected Presentation Switch from a standard 2-gang EU wallmounted keypad. Created with flexibility in mind, the functions and layout of the keys can be easily customized via an intuitive web GUI to meet different application requirements.

Setting up the VPK312 is easy. Simply pair the VPK312 Remote Pad with a Presentation Switch over Ethernet, and the web GUI will assist you through the configuration. With up to 6 Remote Pads can be connected to one Presentation Switch, the VPK312 provides an scalable and affordable control interface to work with Presentation Switches that is perfect for any meeting room, class room, or lecture room.

Features:

12-key Network Remote Pad for ATEN Presentation Switches
Easy pairing with a Presentation Switch via the host Presentation Switch's web console
Effortless configuration via the intuitive web GUI
Fully customizable for the functions and layout of the keys
Dual-color button LEDs for clear indication and visibility
Power redundancy supported when both DC power and Power over Ethernet (PoE) are supplied
Convenient reset of system and network settings using the built-in reset button
Firmware upgradable
Engraved buttons for intuitive port indication and operation


Package Contents
1x VPK312 12-Key Network Remote Pad
1x Faceplate
1x Pack of Button Caps
1x Power Adapter
1x 2-pole Terminal Block
1x User Instructions
