OVERVIEW The D-Link DCS-7110 is an all-in-one, outdoor network camera equipped with industry-leading high definition (Full HD) megapixel resolution and H.264 compression. The DCS-7110 connects to a network to provide high-quality live video over the Internet, capable of capturing video in both day and night environments thanks to its built-in IR LEDs and IR-cut removable (ICR) filter. This feature allows the camera to capture crisp colour images during the daytime and detailed grayscale images at night or in or low-light conditions. SPECIFICATIONS Features Superior Performance * 1/2.7” 2 megapixel CMOS sensor * Real-time H.264/ MPEG-4/ MJPEG * Max. resolution of 1920x1080 at 15 fps Crystal Clear Feed * Four (4) simultaneous streams * Built-in 4 mm, F1.5 fixed lens * 15M IR illumination distance * IR-Cut Removable filter for day/night vision Robust Security * Tamper detection * Motion detection * Privacy mask * IPv6, 802.1x, QoS, CoS * HTTPS secured streaming Full Compatibility * Samba client * IP66 weatherproof * ONVIF compliant * 12V DC, 24V AC and PoE * DI/DO socket Technical Specifications General Hardware Profile * 1/2.7” 2 Megapixel progressive CMOS sensor * 15 metre IR illumination distance * Built-in Infrared-Cut Removable (ICR) Filter module * 4 mm fixed lens , F1.5 * Shutter speed: 1/5 - 1/32,000 seconds * Angle of view: 77.4° (H), 45.1° (V), 88° (D) * Minimum object distance: 0.4 M Image Features * Configurable image size, quality, frame rate, and bit rate * Time stamp and text overlays * 3 configurable motion detection windows * Min Illumination: 0.12 Lux (day mode), 0 Lux (night mode) with IR LED * 5 configurable privacy masks * Flip & mirror * Configurable white balance, shutter speed, brightness, saturation, contrast, sharpness Functionality Video Compression * H.264/MPEG4/MJPEG format compression simultaneously * JPEG for still image * H.264/MPEG-4 multicast streaming Video Resolution * 1920 x 1080 @ 15 fps * 640x480 @ 30 fps * 320x240 @ 30 fps * 1280x800 @ 30 fps * 1280x720 @ 30 fps Network Protocols * IPv4 * IPv6 * TCP/IP * UDP * ICMP * DHCP Client * NTP Client (D-Link) * DNS Client * DDNS Client (D-Link) * SMTP Client * FTP Client * HTTP / HTTPS * Samba Client * PPPoE * UPnP Port Forwarding * RTP/RTSP/RTCP * IP filtering * LLTD * CoS/QoS * SNMP * IGMP * 802.1x * ONVIF Compliant Security * Administrator and user group protection * Password authentication * HTTP and RTSP digest encryption * HTTPS streaming System Requirements * Microsoft Windows 2000, XP, Vista, 7 * Internet Explorer 7 or higher D-ViewCam™ System Requirements * Operating System: Microsoft Windows ® 7/Vista/XP * Web Browser: Internet Explorer 7 or higher * Protocol: Standard TCP/IP Event Management * Motion detection * Event notification and upload snapshots/video clips via HTTP, SMTP or FTP * Supports multiple HTTP, SMTP and FTP servers * Multiple event notification * Multiple recording methods for easy backup Surveillance Software Functions * Remote management/control of up to 32 cameras * Viewing of up to 32 cameras on one screen * Supports all management functions provided in web interface * Scheduled motion triggered and manual recording options External Device Interface * DI and DO for external sensor and alarm Physical Dimensions * 68 x 42 x 51 mm Weight * 808 grams Power * Input: 12 V DC 1.25 A, 24 V AC, 50/60 Hz, 802.3af PoE Max. Power Consumption * 6.3W Temperature * Operating temperature-20 to 50 ° * Storage:-20 to 70 ° Humidity * Operating: 0% to 90% non-condensing Certifications * CE (Class A) * CE LVD (EN60965-1) * FCC (Class A) * ICES-003 * C-Tick
