Popis produktu:

Specs

Peripheral

   Accessory Port
   Ronin Series Accessories (RSA)/NATO Ports
   1/4"-20 Mounting Hole
   Cold Shoe
   Camera Control Port (USB-C)
   Multifunctional Port (USB-C)

   Battery
   Model: BHX715-2150-15.48
   Type: LiPo 4S
   Capacity: 2150 mAh
   Energy: 33.29 Wh
   Voltage: 11.2 V to 17.8 V
   USB Input: 5 V/3 A, 9 V/3 A, 12 V/3 A, 15 V/3 A, 20 V/3 A
   Max Standby Time: Approx. 14 hours*
   Charging Time: Approx. 1 hour**
   Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

   * The 14-hour standby time is achieved with the DJI RS BG33 Battery Grip. The DJI RS BG33 Battery Grip is not available for purchase in India. This data is measured with the gimbal balanced in a level and stationary state. ?When the gimbal is in motion, the operating time will be reduced.
   ** Measured at an ambient temperature of 25° C (77° F) using a 65W charger supporting PD protocol to fully charge the DJI RS BG33 Battery Grip. The DJI RS BG33 Battery Grip is not available for purchase in India.

   Connections
   Bluetooth 5.0
   USB-C Charging Port

   Ronin App Requirements
   iOS 14.0 or above
   Android 9.0 or above

   Languages Supported by the Touchscreen
   English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

   Tested Payload
   3.0 kg (6.6 lbs)

   Maximum Controlled Rotation Speed
   Pan: 360°/s
   Tilt: 360°/s
   Roll: 360°/s

   Mechanical Range
   Pan Axis: 360° continuous rotation
   Roll Axis: -95° to +240°
   Tilt Axis: -112° to +214°

   Axis Lock
   Auto

   Vertical Shooting
   Supported

Mechanical & Electrical Properties

   Operating Frequency
   2.4000-2.4835 GHz

   Bluetooth Transmitter Power
   < 8 dBm

   Operating Temperature
   -20° to 45° C (-4° to 113° F)

   Weight
   Gimbal: Approx. 1193 g (2.63 lbs) (including the Upper and Lower Quick-Release Plates and screws)
   Grip: Approx. 274 g (0.6 lbs)
   Quick-Open Tripod: Approx. 149 g (0.3 lbs)
   Upper and Lower Quick-Release Plates: Approx. 93 g (0.21 lbs) (including screws)

   Dimensions
   Folded: 247.4×115.7×258.7 mm (L×W×H, excluding camera, grip, and the Quick-Open Tripod)
   Unfolded: 223.2×192.2×418.8 mm (L×W×H, including grip, excluding camera and the Quick-Open Tripod)

Accessories

   DJI RS Enhanced Intelligent Tracking Module
   Weight: Approx. 19 g (0.04 lbs)
   Dimensions: 35.9×17.5×38.5 mm (L×W×H)
   Tracking Distance: 0.5-10 m
   Operating Environment: Illuminance > 20 lux
   Trigger Methods: Gimbal trigger, gesture, gimbal touchscreen
   Gesture Functions: Start/stop of tracking, start/stop of recording, framing adjustment
   Power Consumption: Approx. 1 W
   Operating Temperature: -10° to 45° C (14° to 113° F)
   Mounting Method: Magnetic attachment

   Electronic Briefcase Handle
   Weight: Approx. 230 g (0.51 lbs)
   Dimensions: 60×197.5×79.5 mm (L×W×H)
   Standby Power Consumption: Approx. 0.2 W
   Operating Temperature: -20° to 45° C (-4° to 113° F)
