Popis produktu:

CPU
1.Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1150 package
2.L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)
Chipset 1.Intel® H97 Express Chipset

Memory
1.4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
2.Dual channel memory architecture
3.Support for DDR3 1600/1333 MHz memory modules
4.Support for non-ECC memory modules
5.Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)
Onboard Graphics Integrated Graphics Processor - Intel® HD Graphics support: 1.1 x D-Sub port, supporting a maximum resolution of 1920x1200@60Hz
2.1 x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz
* The DVI-D port does not support D-Sub connection by adapter.
3.1 x HDMI port, supporting a maximum resolution of 4096x2160@24Hz or 2560x1600@60Hz
* Support for HDMI 1.4a version.
4.1 x DisplayPort, supporting a maximum resolution of 4096x2160@24Hz or 3840x2160@60Hz
* Support for DisplayPort 1.2 version.
5.Support for up to 3 displays at the same time
6.Maximum shared memory of 512MB

Audio
1.Realtek® ALC1150 codec
2.Support for Sound Blaster X-Fi MB3
3.High Definition Audio
4.2/4/5.1/7.1-channel
5.Support for S/PDIF Out

LAN
1.Qualcomm® Atheros Killer E2201 LAN chip (10/100/1000 Mbit)

Expansion Slots
1.1 x PCI Express x16 slot, running at x16 (PCIEX16)
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

2.1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the PCI Express x1 slots. The PCI Express x1 slots will become unavailable when a PCIe x4 expansion card is installed.
* When installing a x8 or above card in the PCIEX4 slot, make sure to set PCIE Slot Configuration (PCH) in BIOS Setup to x4. (Refer to Chapter 2, "BIOS Setup," "Peripherals," for more information.)

3.2 x PCI Express x1 slots
(The PCIEX4 and the PCI Express x1 slots conform to PCI Express 2.0 standard.)

4.3 x PCI slots

Multi-Graphics
Technology 1.Support for 2-Way AMD CrossFire™ technology

Storage I
nterface Chipset: 1.1 x M.2 PCIe connector
(Socket 3, M key, type 2242/2260/2280 SATA & PCIe SSD support)
2.1 x SATA Express connector
3.6 x SATA 6Gb/s connectors
(M.2, SATA Express, and SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed.)
4.Support for RAID 0, RAID 1, RAID 5, and RAID 10

USB
Chipset: 1.6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header)
2.8 x USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through the internal USB headers)

Internal I/O
Connectors 1.1 x 24-pin ATX main power connector
2.1 x 8-pin ATX 12V power connector
3.1 x M.2 PCIe connector
4.1 x SATA Express connector
5.6 x SATA 6Gb/s connectors
6.1 x USB 3.0/2.0 header
7.3 x USB 2.0/1.1 headers
8.1 x CPU fan header
9.1 x water cooling fan header (CPU_OPT)
10.3 x system fan headers
11.1 x front panel header
12.1 x front panel audio header
13.1 x serial port header
14.1 x Trusted Platform Module (TPM) header
15.1 x S/PDIF Out header
16.1 x Clear CMOS jumper

Back Panel Connectors
1.1 x PS/2 keyboard/mouse port
2.1 x optical S/PDIF Out connector
3.1 x D-Sub port
4.1 x DVI-D port
5.1 x HDMI port
6.1 x DisplayPort
7.4 x USB 3.0/2.0 ports
8.2 x USB 2.0/1.1 ports
9.1 x RJ-45 port
10.6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

I/O Controller
1.iTE® I/O Controller Chip

H/W Monitoring
1.System voltage detection
2.CPU/System temperature detection
3.CPU/CPU OPT/System fan speed detection
4.CPU/System overheating warning
5.CPU/CPU OPT/System fan fail warning
6.CPU/CPU OPT/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.

BIOS
1.2 x 64 Mbit flash
2.Use of licensed AMI UEFI BIOS
3.Support for DualBIOS™
4.PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features
1.Support for APP Center
* Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
@BIOS
EasyTune
EZ Setup
Fast Boot
Game Controller
ON/OFF Charge
Smart TimeLock
Smart Recovery 2
System Information Viewer
USB Blocker
2.Support for Q-Flash
3.Support for Smart Switch
4.Support for Xpress Install

Bundle Software
1.Norton® Internet Security (OEM version)
2.Intel® Rapid Start Technology
3.Intel® Smart Connect Technology
4.Intel® Smart Response Technology

Operating System
1.Support for Windows 8.1/8/7

Form Factor
1.ATX Form Factor; 30.5cm x 21.4cm

Remark
1.Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
2.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
