Popis produktu:

RECERTIFIED

Form Factor: M.2 2280
Interface: PCI-Express 3.0 x4, NVMe 1.3
Total Capacity: 512GB
Sequential Read Speed : up to 3500 MB/s
Sequential Write speed : up to 2600 MB/s
NAND 3D TLC NAND Flash
External DDR Cache DDR3L 2Gb
TRIM & S.M.A.R.T supported


Interface
PCIe 3.0x4, NVMe 1.3
Form Factor
M.2 2280
Total Capacity
512GB
NAND
3D TLC NAND Flash
External DDR Cache
DDR3L 2Gb
Sequential Read speed
Up to 3500 MB/s
Sequential Write speed
Up to 2600 MB/s
Random Read IOPS
up to 350K
Random Write IOPS
up to 302K
Dimension
22 x 2.3 x 80 mm
Mean time between failure (MTBF)
2 million hours
Power Consumption (Active)
Average: R: 5.9W, W:5W
Power Consumption (Idle)
L0/L0s/L1: 900mw
L1.2 < 3mw
Temperature (Operating)
0°C to 70°C
Temperature (Storage)
-40°C to 85°C
Warranty

   1. Limited 5-years or 350TBW.
   2. Limited warranty based on 5 years or 350TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
   *TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.
   3. When the usage of an NVME SSD as indicated by the "Percentage Used" (SMART ID: 05) in SMART page of "GIGABYTE SSD toolbox" reaches 100 means out of warranty. (A new unused product will show the number of 0)

Note

   • Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
   • Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
   • Speeds based on internal testing. Actual performance may vary.
   • 1GB = 1 billion bytes. Actual useable capacity may vary.
