Chipset: Intel® C236 Chipset Revize: 1.0 Rozměrový formát: ATX Form Factor; (30.5cm x 24.4cm) Podpora pro procesory: Intel® Xeon® E3-1200 v5 processors/Intel® Core™ processors/ Intel® Pentium® processors/Intel® Celeron® processors Patice procesoru: LGA1151 Sloty na paměti: 4 x DDR4, Dual channel memory architecture Podpora pro paměti: DDR4 2133 MHz Max.velikost operační paměti: 64 GB Podpora pro paměti typu: ECC, non-ECC Grafická karta: Maximální sdílená paměť 512 MB *Integrated Graphics Processor-Intel® HD Graphics support: *1 x DisplayPort, maximální rozlišení 4096x2304@60 Hz (Podpora DisplayPort 1.2 version) *Integrated Graphics Processor+MegaChips MCDP2800 chip: *1 x HDMI port, maximální rozlišení 4096x2160@60 Hz (Podpora HDMI 2.0 version.) *Podpora 3-Way/2-Way AMD CrossFire™ and 2-Way NVIDIA® SLI™ Technologies Zvuková karta: Creative® Sound Core 3D chip, 2/5.1-channel, (podpora S/PDIF Out) Síťová karta: *1 x Intel® GbE LAN chip (10/100/1000 Mbit)(LAN1) *1 x Rivet Networks Killer™ E2400 chip (10/100/1000 Mbit) (LAN2) Rozšiřující sloty: *1 x PCI Express x16 slot, running at x16 (PCI Express 3.0 standard) *1 x PCI Express x16 slot, running at x8 (PCI Express 3.0 standard) *1 x PCI Express x16 slot, running at x4 (PCI Express 3.0 standard) *3 x PCI Express x1 slots (PCI Express 3.0 standard) RAID řadič: RAID 0, RAID 1, RAID 5, and RAID 10 SATA: *Chipset: *3 x SATA Express connectors *6 x SATA 6Gb/s connectors *ASMedia® ASM1061 chip: *2 x SATA 6Gb/s connectors Firewire: Ne USB: *Chipset: *5 x USB 3.0/2.0 ports na zadním panelu *4 x USB 2.0/1.1 ports (přes interní USB konektor) *Chipset+Renesas® USB 3.0 Hub: *4 x USB 3.0/2.0 ports (přes interní USB konektor) *Chipset+Intel® USB 3.1 Controller: *1 x USB Type-C™ port na zadním panelu, with USB 3.1 support *1 x USB 3.1 Type-A port (red) na zadním panelu Interní porty: *1 x 24-pin ATX main power connector *1 x 8-pin ATX 12V power connector *2 x M.2 Socket 3 connectors *3 x SATA Express connector *8 x SATA 6Gb/s connectors *1 x CPU fan header *1 x water cooling fan header (CPU_OPT) *3 x system fan headers *1 x front panel header *1 x front panel audio header *2 x USB 3.0/2.0 headers *2 x USB 2.0/1.1 headers *1 x Trusted Platform Module (TPM) header *1 x serial port header *1 x Clear CMOS jumper *1 x power button *1 x reset button *1 x Clear CMOS button *1 x audio gain control switch *Voltage Measurement Points *1 x BIOS switch Externí porty: *1 x PS/2 keyboard/mouse port *1 x DisplayPort *1 x HDMI port *1 x USB Type-C™ port, with USB 3.1 support *1 x USB 3.1 Type-A port (red) *5 x USB 3.0/2.0 ports *2 x RJ-45 ports *1 x optical S/PDIF Out connector *5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In/Mic In, Line Out, Headphone) BIOS: AMI UEFI BIOS, 2 x 128 Mbit flash, (podpora DualBIOS™)
