Popis produktu:

Port Ports 1 x R S232
Pin 1 Pin 5
Pin 6 Pin 9
Pin 1 DCD
Pin 2 RXD
Pin 3 TXD
Pin 4 DTR
Pin 5 GND
Pin 6 DSR
Pin 7 RTS
Pin 8 CTS
Pin 9 RI
RS232 Pinout (9 Pin Male) Connector DB9 Connector - 9 Pin Male
FIFO size 128 RX FIFO + 128 TX FIFO
Operating Distance EIA - R S232 Standard
Cable No Cable; Integrated Connector
Port Settings Baud R ate 115,200
115,200
baud
Data Bits 5,6,7 or 8
Parity Odd, E ven, N one, Mark or Space
Stop Bits 1, 1.5 or 2
Flow Control
Tx/Rx Modes Point to Point
Interface OS Compatibility Microsoft Windows 7 32 bit & 64 bit E ditions
Windows Server 2008 32 bit & 64 bit E ditions
Windows Vista 32 bit & 64 bit E ditions
Windows Server 2003 32 bit & 64 bit E ditions
Windows X P 32 bit & 64 bit E ditions
Microsoft Windows 2000
DOS
BUS PCI : Universal PCI is fully compatible with both 3.3Volt and 5Volt PCI
slots.
Approvals Industry Approvals AEO C-TPAT C-Tick Microsoft Certified G old Partner WEEE R oHS IEE C
CB Scheme METL E MC: CE
Microsoft Approvals Windows 7 32 bit & 64 bit E ditions
Windows Server 2008 32 bit & 64 bit editions
Windows Vista 32 bit & 64 bit editions
Windows Server 2003 32 bit & 64 bit editions
Windows X P 32 bit & 64 bit editions
General PCB Layers 4
Power Consumption 190mA @ 5V, 12mA @ 12V
Weight 0.064 kg, 0.14 pounds (UC-246) 0.062 kg, 0.14 pounds (UC-235)
Size null
Box Content Packaging Installation CD including manual, Microsoft signed drivers & utilities
Card uPCI 1xRS232
N o Cable; Integrated Connector
Product Support Warranty Lifetime (online registration required)
Support Lifetime Web, E mail and Phone Support from fully qualified, friendly
staff who work in and alongside the Product Development Team
Additional OEM option Available for bulk buy OEM
Made in the UK
Made In Manufactured in the UK by Brainboxes Winner 2005 E uropean
Electronics Industry Awards “Manufacturer of the Year”
Customisable Brainboxes operate a “Perfect Fit Custom Design” policy for volume
users. More Info: sales@brainboxes.com
