Popis produktu:

CPU:
Intel Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® Extreme/Pentium® D/Pentium® 4 Processors
Compatible with Intel® 05B/05A/06 processors
Support Intel® 45nm CPU

Chipset:
Intel X48
Intel ICH9R
Intel Fast Memory Access Technology

Front Side Bus:
1600/1333/1066/800 MHz

Memory:
4 x DIMM, Max. 8 GB, DDR2 1200*/1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture

Expansion Slots:
2 x PCIe 2.0 x16 , support at full x16, x16 speed
3 x PCIe x1 ( the PCIEx1_1 (black) is compatible with audio slot)
2 x PCI 2.2

CrossFire Support ATI CrossFire graphics cards

Storage:
Southbridge
6 xSATA 3 Gb/s ports
Intel Matrix Storage Technology Support RAID 0,1,5,10
Marvell® 88SE6121 controller:
1 x UltraDMA 133/100/66/33 for up to 2 PATA devices
1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
Silicon Image Sil5723 controller:
2 x SATA 3.0 Gb/s port
Supports RAID 0, 1

LAN:
Dual Gigabit LAN controllers, both featuring AI NET2
Support Teaming Technology

Audio:
SupremeFX II Audio Card
ADI 1988B 8 -Channel High Definition Audio CODEC
Coaxial / Optical S/PDIF out ports at back I/O
ASUS Noise Filter

Back Panel I/O Ports:
1 x PS/2 Keyboard port(purple)
1 x External SATA port
2 x LAN (RJ45) port
6 x USB 2.0/1.1 ports
1 x IEEE1394a port
1 x Clr CMOS switch

Internal I/O Connectors:
3 x USB connectors supports additional 6 USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector
6 x SATA connectors
1 x IEEE 1394a connector
1 x CPU Fan connector
3 x Chassis Fan connector
1 x Power Fan connector
8 x Fan connectors: 1 x CPU / 1 x PWR / 3 x Chassis / 3 x Optional
1 x S/PDIF Out connector
1 x8-pin ATX 12V Power connector
24 Power connector
3 x thermal sensor connector
1 x En/Dis-able Clr CMOS connector
Chassis Intrusion connector
System Panel

BIOS:
16 Mb Flash ROM
DMI 2.0
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.4
ACPI 2.0a
Multi-language BIOS

Manageability:
WOL by PME,WOR by PME,Chasis Intrusion,PXE

Accessories:
External LCD Poster
ASUS Optional Fan
SupremeFX II Audio Card
3 in 1 ASUS Q-Connector Kit
UltraDMA 133/100/66 cable
Floppy disk drive cable
SATA cables
SATA power cables
2-port USB2.0 + IEEE 1394a module
I/O Shield
Cable Ties
User's manual
Support Disc  The hottest 3D Game: S.T.A.L.K.E.R.
Support DVD:
- Drivers and applications
ASUS PC Probe II
ASUS Update
ASUS AI Suite
Futuremark ® 3DMark® 06 Advanced Edition
Kaspersky® Anti-Virus

Form Factor:
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x24.5 cm )
