Popis produktu:

CPU:
Intel® Socket 1156 Core™ i7 Processor/Core™ i5 Processor/
Supports Intel® Turbo Boost Technology
* Refer to www.asus.com for Intel CPU support list

Chipset:
Intel® P55 Express Chipset

Memory:
4 x DIMM, Max. 16 GB, DDR3 2133(O.C.)/2000(O.C.)/1800(O.C.)/1600/1333/1066 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.asus.com or user manual for the Memory QVL(Qualified Vendors List).

Expansion Slots:
2 x PCIe 2.0 x16 (red) support single at x16 or dual at x8 mode
1 x PCIe x16 (white) supports at x4 mode
2 x PCIe x1
2 x PCI 2.2

Multi-GPU Support:
Supports NVIDIA® SLI™ Technology / ATI® CrossFireX™ Technology

Storage:
Intel® P55 Express Chipset built-in
6 xSATA 3.0 Gb/s ports
Intel Matrix Storage Technology Support RAID 0,1,5,10
JMicron® 322 controller and 2 x JMicron® 363 controllers:
- 2 x SATA 3.0 Gb/s port (Red) supporting Hardware RAID 0 and 1 (SPD_HDD1 + SPD_HDD2)
- 1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
- 2 x SATA 3.0 Gb/s port (White) - SATA_ODD1 + SATA_ODD2

LAN:
Realtek® RTL8110SC Gigabit LAN controller
GameFirst

Audio:
SupremeFX X-Fi discrete Audio Card
8-Channel High Definition Audio CODEC
EAX® Advanced™ HD 4.0
X-Fi CMSS®-3D
X-Fi Crystalizer™
Creative ALchemy
Supports 1 x S/PDIF out header
Supports Coaxial/Optical S/PDIF out ports on rear
Blu-ray support

IEEE 1394:
2 x 1394a ports (1 port at back I/O, 1 port onboard)

USB:
14 USB 2.0/1.1 ports (5 ports at mid-board, 9 ports at back panel)

Overclocking Features:
Extreme Engine Power Design
ROG Connect
CPU Level Up
Memory Level Up
Speeding HDD
iROG
Extreme Tweaker
Loadline Calibration
Intelligent overclocking tools:
Overclocking Protection:
Special Features  MemOK!
MemPerfect
ProbeIt
Onboard Switches: Power / Reset / Clr CMOS (at rear)
Q-Fan Plus
ASUS EPU
ASUS MyLogo3
ASUS Fan Xpert
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS Q-Connector
ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
ASUS Q-Slot
ASUS Q-DIMM

Back Panel I/O Ports:
1 x External SATA
1 x IEEE 1394a
1 x LAN(RJ45) port
1 x Clr CMOS switch
1 x ROG Connect On/Off switch
1 x PS/2 Keyboard port (purple)
9 x USB 2.0/1.1 (1 port for ROG Connect)

Internal I/O Connectors:
3 x USB connectors support additional 5 USB 2.0 ports (1 port reserved for ROG Connect @ rear)
1 x IEEE 1394a connector
10 x SATA connectors: 2 x Speeding HDD SATA connectors (Red) / 2 x SATA_ODD (White) / 6 x standard SATA connectors (Gray)
8 x Fan connectors: 1 x CPU / 1 x PWR / 3 x Chassis / 3 x Optional
3 x thermal sensor connectors
1 x 24-pin ATX Power connector
1 x 8-pin ATX 12V Power connector
1 x En/Dis-able Clr CMOS header
5 x ProbeIt measurement points
1 x ROG light connector
1 x Go Button
System panel connector

BIOS:
16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI2.0a Multi-Language BIOS

Manageability:
WOL by PME,WOR by PME,PXE

Accessories User's manual
1 x I/O Shield
1 x ROG Connect Cable
1 x SLI Cable
1 x SupremeFX X-Fi Audio Card
1 x 2-in-1 ASUS Q-Connector Kit
3 x 2-in-1 SATA signal cables
1 x 2-port USB2.0 + ESATA module
1 x Cable Ties
1 x ROG theme label
1 x 12-in-1 ROG Cable Label

Support Disc:
ASUS PC Probe II
ASUS AI Suite
ASUS Update
Kaspersky® Anti-Virus
Support DVD:
- Drivers and applications
Sound Blaster X-Fi Utility
ASUS TurboV EVO utility

Form Factor:
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
