Popis produktu:

Drive Configuration
Device Location: Plug-in Module
Form Factor: 2.5"
Storage Capacity: 1 TB
Supports Data Channel: SATA III-600
External Data Bit Rate: 6 Gbps
Sector Capacity: 512 B
Flash Memory Cell Technology: Triple-Level Cell
Performance
Maximum Random Read Rate: 92000 IOPS
Maximum Random Write Rate: 83000 IOPS
Maximum Sequential Read Rate: 530 MB/s
Maximum Sequential Write Rate: 500 MB/s
Interface Provided
SATA III Interface Quantity: 1
Reliability
Non-Recoverable Errors: 1 per 10^15
Mean Time Between Failures: 1500000 hr
Solid State Drive Features: AES 256-bit Encryption
Adaptive Thermal Monitoring
Dynamic Write Acceleration
Compliant Storage Standards: S.M.A.R.T.
Shock Tolerance Storage: 1500G @ 0.5ms
Vibration Tolerance Storage: 3.1G @ 5-800Hz
Power Consumption
Nominal Supply Voltage: 5 V
Maximum Supply Voltage: 5.5 V
Minimum Supply Voltage: 4.5 V
Maximum Power Consumption: 75 mW
Minimum Power Consumption: 4 mW
Environment
Maximum Operating Ambient Temperature: 70 °C
Minimum Operating Ambient Temperature: 0 °C
Maximum Operating Humidity: 95 %
Minimum Operating Humidity: 5 %
Maximum Non-Operating Ambient Temperature: 85 °C
Minimum Non-Operating Ambient Temperature: -40 °C
Dimensions & Weight Device
Depth (mm): 100.45 mm
Height (mm): 7 mm
Width (mm): 69.85 mm
Nominal Weight: 0.056 kg
Package Type: OEM
Features
• Micron® 3D TLC NAND Flash
• RoHS-compliant package
• SATA 6 Gb/s interface
• TCG/Opal 2.0-compliant self-encrypting drive
(SED)
• Compatible with Microsoft eDrive®
• Hardware-based AES-256 encryption engine
• ATA modes supported
– PIO mode 3, 4
– Multiword DMA mode 0, 1, 2
– Ultra DMA mode 0, 1, 2, 3, 4, 5, 6
• Industry-standard, 512-byte sector size support
• Hot-plug/hot-remove capable (2.5")
• Device sleep (DEVSLP), extreme low-power mode
• Native command queuing support with 32-command
slot support
• ATA-8 ACS3 command set compliant
• ATA security feature command set and password
login support
• Secure erase (data page) command set: fast and secure
erase
• Sanitize device feature set support
• Self-monitoring, analysis, and reporting technology
(SMART) command set
• Dynamic write acceleration
• Adaptive thermal monitoring
• Power loss protection for data-at-rest
• Performance1, 2
– PCMark® Vantage (HDD test suite score): Up to
84,000
– Sequential 128KB READ: Up to 530 MB/s
– Sequential 128KB WRITE: Up to 500 MB/s
– Random 4KB READ: Up to 92,000 IOPS
– Random 4KB WRITE: Up to 83,000 IOPS
– READ/WRITE latency: 85µs/40µs (TYP)
• Reliability
– MTTF: 1.5 million device hours3
– Static and dynamic wear leveling
– Uncorrectable bit error rate (UBER): <1 sector
per 1015 bits read
• Low power consumption
– Device Sleep numbers: <4mW (256GB to 1TB)
– DIPM numbers: 110mW TYP4
• Endurance: Total bytes written (TBW)
– Up to 400TB
• Capacity (unformatted): 256GB, 512GB, 1024GB,
2048GB
• 2.5-inch × 7mm form factor
• M.2 2280 form factor
• Secure firmware update with digitally signed firmware
• Operating temperature
– Commercial (0°C to +70°C)5
Notes: 1. Typical I/O performance numbers as measured
fresh-out-of-the-box (FOB) using Iometer
with a queue depth of 32 and write
cache enabled.
2. 4 KB transfers used for READ/WRITE latency
values.
3. The product achieves a mean time to failure
(MTTF) based on population statistics not
relevant to individual units.
4. Active average power measured during execution
of MobileMark® with DIPM
