Chipset: AMD® B450 Rozměrový formát: ATX Form Factor Podpora pro procesory: 1st, 2nd and 3rd Gen AMD Ryzen™, Ryzen™ with Radeon™ Vega Graphics, 2nd Gen AMD Ryzen™ with Radeon™ Graphics and Athlon™ with Radeon™ Vega Graphics Desktop Processors for Socket AM4 Patice procesoru: AM4 Sloty na paměti: 4 x DDR4, Dual channel memory, ECC UDIMM memory (non-ECC mode) + non-ECC UDIMM memory Podpora pro paměti: *AMD Ryzen Gen3 (R5/R7/R9) 1866/ 2133/ 2400/ 2667Mhz (by JEDEC), 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866/ 4000/4133 MHz (by A-XMP OC MODE) *AMD Other CPU 1866/ 2133/ 2400/ 2667Mhz (by JEDEC), 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466MHz (by A-XMP OC MODE) Max.velikost operační paměti: 64 GB Podpora více GPU *2-Way AMD® CrossFire™ Technology Grafika (pouze pro CPU s integrovanou grafikou) -1x DVI-D port, s rozlišením až 1920x1200 @60Hz -1x HDMI™ 1.4 port, s rozlišením až 4096x2160 @30Hz, 2560x1600 @60Hz Zvuková karta: Realtek® ALC892 Codec Síťová karta: Realtek® 8111H Gigabit LAN controller Rozšiřující sloty: -1x PCIe 3.0 x16 slot (PCI_E1) *1st, 2nd and 3rd Gen AMD Ryzen™ support x16 mode *Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support x8 mode *Athlon™ with Radeon™ Vega Graphics support x4 mode -1x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode) -4x PCIe 2.0 x1 slots RAID řadič: RAID 0, RAID 1 a RAID 10 SATA: 6x SATA 6Gb/s ports M.2: 1x M.2 slot (Key M) Interní porty: *1x 24-pin ATX main power connector *1x 8-pin ATX 12V power connector *6x SATA 6Gb/s connectors *2x USB 2.0 connectors (support additional 4 USB 2.0 ports) *1x USB 3.2 Gen1 connectors (support additional 2 USB 3.2 Gen1 ports) *1x 4-pin CPU fan connector *1x 4-pin water-pump-fan connector *4x 4-pin system fan connectors *1x TPM module connector *1x Front panel audio connector *2x System panel connectors *1x Serial port connector *1x Parallel port connector *1x Chassis Intrusion connector *1x Clear CMOS jumper *2x 5050 RGB LED strip 12V connectors Externí porty: *1x PS/2 Combo Port *2x USB 3.2 Gen1 *1x LAN Port *HD Audio Connectors *Flash BIOS Button *2x USB 2.0 Ports *1x DVI-D Port *1x HDMI Port *2x USB 3.2 Gen2 Stránky výrobce: https://www.msi.com/Motherboard/B450-GAMING-PLUS-MAX/Overview
