Chipset: AMD B550 Rozměrový formát: ATX Form Factor (305 mm x 244 mm) Podpora pro procesory: AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series desktop processors Patice procesoru: AM4 Pozice na paměti: 2x DDR4 DIMM Podpora pro paměti: *1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC *AMD Ryzen 4000 G-Series processors support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600/ 4733/ 4800/ 5000/ 5100/ 5300+ (Max. 5800) MHz by A-XMP OC MODE *3rd Gen AMD Ryzen processors supports DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600/ 4733/ 4800/ 4866/ 5000/ 5100+ MHz by A-XMP OC MODE Max.velikost operační paměti: 64 GB Podpora pro paměti typu: DDR4 *Dual channel memory architecture *Supports non-ECC UDIMM memory *Supports ECC UDIMM memory (non-ECC mode) *Supports un-buffered memory Grafická karta: *Integrated Graphics Processor (na základě procesoru) Multi GPU: Supports 2-Way AMD CrossFire™ Technology Zvuková karta: *Realtek® ALC1220P Codec Síťová karta: *1x Realtek® RTL8125B 2.5Gbps LAN controller *Intel® Wi-Fi 6 AX200 *Bluetooth® 5.1 Rozšiřující sloty: *1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) *1x PCIe 3.0 x16 slot (PCI_E4), supports x4 speed *2x PCIe 3.0 x1 slots (PCI_E2 & PCI_E3) RAID řadič: 0, 1, 10 SATA: *6x SATA 6Gb/s M.2: *4x M.2 slots USB: *zadní USB porty ( celkem 8 ) *3x USB 3.2 Gen 2 10Gbps ports *1x USB 3.2 Gen 2 Type-C 10Gbps port *4x USB 2.0 ports *přední USB porty ( celkem 7 ) *1x USB 3.2 Gen 2 10Gbps Type-C port *2x USB 3.2 Gen 1 5Gbps ports *4x USB 2.0 ports Interní porty: *1x 24-pin ATX main power connector *2x 8-pin ATX 12V power connector *1x 6-pin PCIE power connector *6x SATA 6Gb/s connectors *4x M.2 slots (M-Key) *1x USB 3.2 Gen 2 10Gbps Type-C port *1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) *2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) *1x 4-pin CPU fan connector *1x 4-pin water-pump fan connector *6x 4-pin system fan connectors *1x Front panel audio connector *2x System panel connectors *1x Chassis Intrusion connector *1x 4-pin RGB LED connectors *2x 3-pin RAINBOW LED connectors *1x 3-pin CORSAIR LED connector *1x TPM module connector *1x Clear CMOS jumper *1x Power button *1x Reset button Externí porty: *Clear CMOS Button *Keyboard / Mouse *4x USB 2.0 Ports *2.5G LAN *Wi-Fi /Bluetooth *HD Audio Connectors *Flash BIOS Button *HDMI 2.1 Port *3x USB 3.2 Gen 2 10Gbps (Type-A) *1x USB 3.2 Gen 2 10Gbps (Type-C) *Optical S/PDIF-Out Stránka výrobce: https://www.msi.com/Motherboard/MEG-B550-UNIFY-X
