Popis produktu:

System Form Factor 5U Rackmount
Chassis Name VX50
Dimension (D x W x H) 26.8" x 16.7" x 8.7" (680 x 425 x 220mm)
Motherboard S4985G3NR-SI
Board Dimension MEB, 13"x16.2" (330x411mm)
Gross Weight 55 kg
Front Panel Buttons (1) PWR / (1) RST / (1) ID
LEDs (1) PWR / (1) HDD / (2) LAN / (1) ID
I/O Ports (2) USB ports
External Drive Bay Type / Q'ty 3.5" Hot-Swap / (8) / (3) 5.25" device bays (pre-installed one standard DVD-ROM) / (1) Slim optical drive bay
Supported HDD Interface SATA-II 3.0Gb/s
Internal Drive Bay Type / Q'ty (4) 3.5" fixed (upgradable to hot swap bays)
Supported HDD Interface SATA-II 3.0Gb/s
System Cooling Configuration FAN (3) 12cm fans
Peripherals Type of ODD / Q'ty Standard type DVD-ROM / (1)
Power Supply Type ERP1U
Input Range Full-range AC(100-240V)
Frequency 60 Hertz
Output Watts 1620 Watts
Efficiency PFC
Redundancy 3+1
Processor Supported CPU Series AMD 45nm Quad-Core Opteron 8300/8400 Series Processors (Barcelona / Shanghai / Istanbul) / Support AMD Dual Dynamic Power Management (DDPM) feature / Support AMD HyperTransport (HT1 and HT3) Technology
Socket Type / Q'ty LGA 1207-pin / (8), (4) on M4985-SI
Thermal Design Power (TDP) wattage 115W(Quad-Core) / 95W(Dual-Core)
System Bus Up to 4.4 GT/s Hyper-Transport link support
Chipset Chipset NVIDIA NFP2200 / NFP2050
Super I/O Winbond W83627
Memory Supported DIMM Qty (16) DIMM slots
DIMM Type / Speed Registered ECC DDR2 / 800/667/533
Capacity Up to 128GB
Memory channel 4 Channels (2 Channels per CPU)
Memory voltage 1.5V
Expansion Slots PCI-E (2) PCI-E x16 slots / (2) PCI-E x16 slots (w/ x4 link)
PCI (1) PCI 32-bit slot
LAN Port Q'ty (2)
Controller Intel 82541PI
PHY Marvell 88E1111
Graphic Connector type D-Sub 15-pin
Resolution 1600x1200@60Hz
Chipset XGI Z7
Video RAM 16MB
I/O Ports USB (4) ports (2 at front, 2 at rear)
COM (1) DB-9 COM port
PS/2 (1) PS/2 connector (for Keyboard and Mouse)
VGA (1) D-Sub 15-pin port
RJ-45 (3) ports
System Monitoring Chipset ADT7476
Voltage Monitors voltage for CPU, memory, chipset & power supply
Temperature Monitors temperature for CPU & system environment
LED Fan fail LED indicator / Over temperature warning indicator
Others Chassis intrusion detection / Watchdog timer support
Server Management Optional SMDC M3291 IPMI 2.0 remote system management card
M3291 Feature Renesas H8S2167 Baseboard Management Controller (BMC) / Supports remote power on/off and reset (IPMI over LAN) / Shared management NIC / Properitary card interface (2 x 25pin header) / SOL (remote serial console redirect over LAN)
BIOS Brand / ROM size Phoenix / 1MB
Feature Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot / ACPI 2.0 power management /Power on mode after power recovery / User-configurable H/W monitoring / Auto-configurable of hard disk types / Multiple boot options
Operating System OS supported list Please refer to our OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating Environment Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Complaint Yes
Package Contains Barebone (1) VX50B4985-SI Barebone
Manual (1) MB User's manual + (1) BB User's manual
Installation CD (1) TYAN installation CD
Heatsink / Cooler (4) CHSK-0340, 1207-pin CPU heatsinks with fan
Rail kit (1) CRAL-0140, sliding rail kit for VX50
Mounting Ear (1) CEAR-0060, mounting ear kit
Others (1) screw pack / (1) COTH-0180, Foot stand for chassis / (1) CFBZ-0060, Bezel door, ABS
Cable DVD-ROM (1) CCBL-0500, CD-ROM flat cable
Power Cord (4) CCBL-0310, US type power cords / (4) CCBL-0300, EU type power cords
Optional accessories for future upgrade SMDC IPMI Card M3291
Peripheral (1) CFDD-0010, 3.5" FDD / (1) CSTK-0050, SATA DVD-ROM upgrade kit
Cable (1) CCBL-046C, power cable for high performance VGA card
SCSI (1) CSTK-0011, SCSI upgrade kit
