Display Specifications Size 13.3" Brightness 350 cd/m2 with Optical bonding Contrast Ratio 800:1 Resolution 1920x1080 Touch Multi-touch Projected Capactive with Glove/Rain/Stylus Modes Sensors Light sensor/ G sensor / Gyro / E-compass System Specification Processor Intel Core i5-5200U Broadwell 2.2GHz (turbo to 2.7GHz) Memory 4GB SODIMM DDR3L-1600 (up to 16GB) Storage 1 x 128GB M.2 MLC SSD (up to 1TB with 2 x SSD) 2 x Internal M.2 slots Audio 1 x Built-in Digital Mic, 2 x 1W Speaker Wireless Communication WLAN Intel® Dual Band Wireless-AC 7265 802.11 a/b/g/n/ac (M.2) Bluetooth Intel® Dual Band Wireless-AC 7265 Bluetooth 4.0 Dual Mode (Classic + Low Energy)(M.2) WWAN Optional 4G (LTE,HSPA+,GSM/GPRS/EDGE,EV-DO Rev A, 1xRTT) Optional 3G (HSPA+,GSM/GPRS/EDGE) GPS u-Blox 6Q I/O Connectors 1 x HDMI 1 x RJ45-10/100/1000 Mbps LAN 1 x Serial Com Port 2 x USB 3.0, 2 x USB 2.0 1 x Headphone Combo 1 x Power (DC in) 1 x Docking Connector 1 x SD Card Slot 1 x Service Windows (access to 2 x M.2 SSD cards and 1 x mini PCI-e WWAN card) 1 x Optional Expansion Window (Smart Card Reader/Barcode) In front Control LED indicator Power / Battery / RF / SSD Mechanical and Environment Dimensions (W x L x H) 338.2 x 240 x 30 mm (13.3 x 9.4 x 1.18 inches) Net Weight (kg) 2.4 Kg Operating Temperature -10°C to 50°C Storage Temperature -20°C to 60°C IP Proof IP65 Operating Humidity 30% to 80% RH, non-condensing Certifications CE, FCC, IC, UL Vibration MIL-STD-810G Method 514.6 Procedure Shock MIL-STD-810G Method 516.6 Procedure I Drop MIL-STD-810G Method 516.6, 4 ft to concrete Housing Rear Magnesium Alloy Die-Casting Design Fanless ESD 12kV/12kV Power Management Power Input 12 to 19V Battery 7.4V, 10280 mAh (typ.) Li-Polymer Battery (2S2P) Optional Hot-Swappable Battery Operating Time 11 Hours(BAPCo TabletMark v3) Adapter 100-240V, 50-60Hz, 19V DC Product Specification OS Windows 10 IoT Enterprise / Windows Embedded 8.1 Industry Pro 64-bit / Windows Embedded Standard 7 (WS7P) 64-bit / Windows 7 Pro for Embedded Systems 64-bit RFID Optional HF RFID 13.56MHz reader (ISO15693, ISO14443A, ISO18092) Barcode Optional short range 1D/2D Motorola SE4500 barcoder reader Camera 5MP auto-focus camera with LED flash at rear 2MP camera at front Security Security Password security for user and hard disk lock Kensington lock slot Trusted platform module (TPM) V1.2 Computrace® theft protection support Mobile Device Management SOTI MobiControl compatible

Příslušenství (součást balení) • Adapter and Power Cord (100-240VAC to 19VDC@3.42A) • Standard Battery (7.4V / 10280 mAh Li-Polymer Battery, 2S2P) • Stylus (Length: 120mm) • Stand with Integrated Handle (Metallic stand with rubberized protection pads to prevent slipping)

Volitelné příslušenství (lze dokoupit samostatně) • VESA Mounting kit (75x75mm and 100x100mm VESA Mount Points) • Shoulder Strap (Adjustable cross-body strap (cm) with pad) • Battery Charger (Dual-bay charging dock) • Active Pen (2 x Side Buttons (Eraser, Barrel)) • Vehicle Charger (11~32V DC IN, 19V/ 3.42A DC OUT)
