Electrical & Physical Characteristics AC Input Range Voltage 200 ~ 240VAC ± 10% Vout Output Load Rating Combined Power Frequency 50 ~ 60Hz ± 3 Imin Imax Ipeak AC Input Current (Rated) Voltage 200 ~ 240VAC +3.3V 0.1A 20A 140W 700W Current 8A +5V 0.2A 20A PFC Type Active PFC +12V 0.1A 58A 60A 696W Power Factor Max 99% -12V 0.0A 0.3A 3.6W Inrush Current Limit (@ Cold start at 25°C) 115VAC - +5VSB 0.0A 2.5A 3.5A 12.5W 230VAC Max 100A Ambient Temperature Efficiency Max 87% @ 230VAC, Typical load Operation 0 ~ 40°C DC Output Voltage Regulations Vout Regulation Range At Full Load Storage -20 ~ 70°C +3.3VDC ±5% +3.14 ~ +3.47V Ambient Humidity +5VDC ±5% +4.75 ~ +5.25V Operation 5% ~ 95%RH +12VDC ±5% +11.4 ~ +12.6V Storage 5% ~ 95%RH -12VDC ±10% -10.8 ~ -13.0V Protection Features +5VSB ±5% +4.75 ~ +5.25V Over Voltage Protection(OVP) DC Output Ripple & Noise Vout Standard Range At Full Load Under Voltage Protection(UVP) +3.3VDC 50mV +5VDC 50mV Short Circuit Protection(SCP) +12VDC 120mV Over Power Protection(OPP) -12VDC 120mV Dimensions 157(L) x 150(W) x 86(H) mm +5VSB 50mV Weight 2.2kg
